Taoxing Pneumatic Flat Printing Machine TX-360M for Circular Saw Blade
- Model
- TX-360M
Item specifics
- Max printing area
- 200*300mm
- Max size of frame
- 380×350mm
- Max. diameter
- 300mm
- Max. Printing speed
- 1200 pcs/h
- Max. workpiece height
- ≤300mm
- Air consumption
- 6bar
Review
Description
Application
This machine is a professional screen printing machine designed specifically for printing circular saw blades, with 360-degree printing throughout the process.
Features
1 Microprocessor control each function with high automation and easy operation;
2 4-digit auto counter built in;
3 Cylindrical/conical printing function available;
4 Auto ink squeegeeing and flooding, worktable elevating to assure easy operation and consistent print quality;
5 Printing stroke and speed are adjustable to meet different requirements;
6 Fine adjustment available on squeegee left/right position to make substrate alignment easy and exact;
7 Fine adjusted available on worktable up/down and plane angle, and frame front/rear, left/right and up/down with high printing precision.
Main paramerter
|
Product name
|
Cylindrical screen
printing machine |
|
Product model
|
TX-360M
|
|
Application area
|
circular saw blades
|
|
Printing Speed
|
1200 pcs/h
|
|
Maximum Print size
|
200*300cm
|
Maximum Screen Frame Size | 380×350mm |
Max. diameter | 300mm |
Voltage | 220V/110V 50-60Hz 60W |
Max. workpiece height | ≤300mm |
Air consumption | 6bar |
Printing Samples
